8.2.8 Flange ANSI Class (code 39)
Connection type flange ANSI (code 39)
MG DN
20 15
20
25
25 32
40 40
50
Dimensions in mm
MG = diaphragm size
n = number of bolts
1) Connection type
Code 39: Flange ANSI Class 125/150 RF, face-to-face dimension FTF EN 558 series 1, ISO 5752, basic series 1, length only for body config-
uration D
2) Valve body material
Code 1: PVC-U, grey
www.gemu-group.com
FTF
1) , body material PVC-U (code 1)
NPS ød øD
1/2" 34.0 95.0
3/4" 41.0 105.0
1" 50.0 115.0
1¼" 61.0 140.0
1½" 73.0 150.0
2" 90.0 165.0
2)
FTF H
130.0 36.0 10.0
150.0 38.0 12.0
160.0 39.0 13.0
180.0 41.0 15.0
200.0 63.2 23.2
230.0 63.2 23.2
51 / 64
H1 øk øL
60.0 16.0
70.0 16.0
79.0 16.0
89.0 16.0
98.0 16.0
121.0 19.0
8 Dimensions
n
4
4
4
4
4
4
