Gemü R647 Betriebsanleitung Seite 40

7 Technical data
Control pressure/operat-
ing pressure diagram:
Kv values:
Filling volume:
GEMÜ R647
10
9
8
7
6
5
4
3
2
1
0 1
MG
20
25
40
MG = diaphragm size, Kv values in m³/h
Kv values determined acc.to DIN EN 60534 standard, inlet pressure 5 bar, Δp 1 bar, PVC-U valve body and soft
elastomer diaphragm.
The Kv values for other product configurations (e.g. other diaphragm or body materials) may differ. In general,
all diaphragms are subject to the influences of pressure, temperature, the process and their tightening torques.
Therefore the Kv values may exceed the tolerance limits of the standard.
The Kv value curve (Kv value dependent on valve stroke) can vary depending on the diaphragm material and
term of use.
MG
20
25
40
DN 15 - 25
DN 32 - 50
2 3 4
Operating pressure [bar]
DN
15
20
25
32
40
50
Actuator size
ED
FD
HD
40 / 64
5 6
Kv values
6.0
10.0
12.0
20.0
42.0
46.0
Filling volume [dm³]
0.27
0.69
1.42
