Standard Operation - Pcl Da97 Schnellstartanleitung

Start-up
1. Turn on power supply.
2. Display will show all LCD digits check.
3. Display will show the current Firmware version number e.g.
'3.2.3' (German 3.2.1).
4. Display will show Program model variant '300' ( psi default)
or '302' (bar default) or '315' German.
5. Display will show the application, 'Std'
6. After 10 seconds the display will show 'PCL'.
7. The unit will then display the set default pressure.
Do not connect the hose to the tyre during start-up or E5
will show

Standard Operation

Inflation and deflation
1. Set desired pressure, by touching either
2. Connect the hose to the tyre.
3. Automatic inflation will commence to the set pressure,
periodically stopping to display the pressure of the tyre.
4. If the pressure in the tyre is below 3 psi, 0.2 bar or 20 kpa,
the process will not commence until
5. When the Set pressure is reached, the buzzer will sound
and the display will show 'END' with the final pressure.
6. Remove the hose from tyre.
7. For selection of alternative pressure unit touch
For pay air units inset sufficient coins, unit will then operate as
above.
For adjustments to Inflators parameters
please refer to your Distributor or PCL.
This unit is not suitable for the filling of
bicycle tyres with a standard (Presta,
Woods) bicycle valves and adapters. Over
fill of the tyre is possible!
User Inspection mode
It is possible to set the inflator to act as a pressure gauge.
The display resolution is changed and can be used to reference the
inflator against a calibrated pressure source. The inflator automatic
cycle is inhibited.
To access:-
1. Touch and together
2. The unit will beep but the display will not change
3. Touch 5 times
(if this is not undertaken within 10 seconds, the Inflator
reverts back to normal Inflator mode)
4. Display will show the pressures to the minimum resolution:
psi = 0.1 / Bar = 0.01 / kpa = 1 / kg/cm = 0.01
5. Connect the hose to the tyre and the display will show the
pressure in the tyre
6. When complete, touch any button to return to the last set
mode.
Coin count mode
1.
2.
3.
4.
5.
6.
Service/Maintenance
There is no requirement to service the following items:
1.
or
2.
is touched.
Periodically
•
.
•
•
Working safety instructions
Since the unit is not explosion-proof, the device should not be
installed in areas where explosions are possible. Consideration
must be given to the requirements relative to Hazardous Area
Standards for your region or country.
The unit is designed and built to the relevant basic health and
safety requirements of the EC.
The PCL tyre inflators are exclusively approved for the
dispensing of air/N
follow this purpose as well as modifications to the product
will be deemed to be improper use. The manufacturer is not
liable for damages caused by improper use, the risk lies
solely with the user.
www.pclairtechnology.com
PCL Air and AdBlue Tower
Touch the and together.
The unit will beep but the display will not change.
Touch 5 times.
(if this is not undertaken within 10 seconds, the Inflator
reverts back to normal Inflator mode).
The display will show 'coi' and then the coin count flashing
alternately.
Touching the again will show 'to' and then the token
count flashing alternately.
After 25 seconds the display will revert back to default
pressure.
Pressure Transducer
Electric Control Board
If these are faulty they can only be
replaced by a competent person.
Please refer to an Authorised dealer.
Check the hose (only wire braided hose must be used).
Check the tyre connector.
Remove air input supply and tyre hose from the head.
Unscrew captive sintered filters from filter housings and
clean or replace.
This product can be dangerous if used
improperly. Children should not be
allowed to use this equipment, as
incorrect setting can allow tyre to be over
inflated and a subsequent tyre burst/
explosion can occur!
and AdBlue. Each use which doesn't
2
