- Fill the gearbox D (fig. 28) with 0.8 l transmission oil
(GP80W90).

Change of grease in mower elements

7.6
Replace the grease in the mower elements every 500 working
hours or every 1,000 hectares.
Follow the directions listed hereafter.
- Remove the mower disc.
- Dismount the bearing housing A (fig. 29) from the element.
Make sure that the shims B remain in place.
If several bearing housings need to be dismounted, care
!
should be taken that they are fitted back on the original
mower elements.
- Remove the grease from the element. Do not use a solvent
since it may affect the sealing of the bearings and/or rinse
the grease fill out of the bearings.
- Fill the elements with 95 grams of grease (grease
classification NLGI 0, type calcium-lithium soap or
lithium soap/Shell Alvania WR 0).
Measure the grease quantity carefully. An incorrect
!
quantity may cause overheating and damage of the
element.
- Place the bearing housing on the element. Turn the hub C
(fig. 29) so that it is aligned with the hub of the adjacent
mower element (fig. 30).
- Apply Loctite 243 to the thread of the fillister head screws
and tighten them with a torque of 36 Nm (3,6 kgm).
- Check at the catellated nut the presence of the O-ring in the
pressure piece.
- Fit the mower disc. Tighten the castellated nut with a
torque of 150-250 Nm (15-25 kgm) and secure it with a
split pin. Make sure that the split pin does not protrude
above the pressure piece.
D
36 Nm
(3,6 kgm)
0.095 kg
NLGI 0
150-250 Nm
(15-25 kgm)
43
28
C
A
B
29
30
