- Check all bolts and nuts for tightness. Pay particular
attention to the bolts which secure the skids and wear
plates (fig. 23).
When tightening loose bolts/nuts the torques listed below
should be applied.
M6 M8 M10 M12 M14 M16 M20 M24
Nm 10 25 50
kgm 1,0 2,5 5,0
- Check the gearboxes for oil leakage
(for oil change - see chapter 7.5).
- Convince yourself of the presence and undamaged condi-
tion of all safety decals on the machine (fig. 24).
