Ece r44/04, gr. 2–3, 15-36 kg

Werbung

REMOVING THE SEAT COVER
The cover of the infant seat consists of four parts (Headrest flap, headrest, shoulder
part cover, booster cover and/or seat surface cover).This is complemented by the
safety cushion cover.
The four covers of the seat are fitted into the cover attachment channels on the
edge of the infant seat and are held in position at several places by press-studs (see
image).
Once all studs have been released, the single parts of the cover can be removed
from the cover attachment channels.
In order to put the covers back on the seat, proceed in the reversed order as
removing them.
WARNING! The child car seat must never be used without the cover.
REMOVING THE COVER FROM THE HEADREST FLAP
Pull the opening of the cover over the adjustment lever so that the cover does not get
jammed on the lever when pulling it up to remove it.
REMOVING THE COVER FROM THE HEAD SUPPORT
Release the two press-studs at each side of the rear of the shoulder area. Pull the
cover out of the cover attachment channel.
REMOVING THE COVER FROM THE SHOULDER PART
Pull the cover out of the cover attachment channel.

RIMOZIONE DELLA FODERA DEL SEGGIOLINO

La fodera del seggiolino è composta da quattro parti (aletta del poggiatesta,
poggiatesta, fodera dell'area della spalla, fodera dell'elevatore e/o fodera della
superficie di seduta). Il tutto è completato dalla fodera del cuscino di sicurezza.
Le quattro fodere del seggiolino sono inserite nelle guide di attacco della fodera sui
bordi del seggiolino e sono tenute in posizione in vari punti da bottoni automatici
(vedere figura).
Una volta sbloccati tutti gli automatici, le singole parti della fodera possono essere
rimosse dalle guide di attacco della fodera.
Procedere in ordine inverso rispetto alla rimozione al fine di ricollocare le fodere sul
seggiolino.
ATTENZIONE! Il seggiolino non deve mai essere usato senza la fodera.
RIMOZIONE DELLA FODERA DALL'ALETTA DEL POGGIATESTA
Tirare l'apertura della fodera oltre la leva di regolazione, in modo che la fodera non
resti incastrata sulla leva al momento dell'estrazione.
RIMOZIONE DELLA FODERA DAL POGGIATESTA
Rilasciare i due bottoni automatici su ogni lato del retro dell'area della spalla. Estrarre
la fodera dalla guida di attacco della fodera.
RIMOZIONE DELLA FODERA DALL'AREA DELLA SPALLA
Estrarre la fodera dalla guida di attacco della fodera.
23
