LIST OF PARTS:
Lp.
1
Bracket
2
Handles
3
Speed change buttons
4
Panel
5
Cover
6
Cover
7
Tile
8
Contact plate
9
Cover left
10
Right shield
11
Slat
12
Aluminium covers 22*75*1397L
13
Sidebars 7.4*79.7*1243L
14
Cap 73.9*16.7*1173L
15
Handle covers 261*70*39
16
Bottom cover 250*50*39
17
Axle
18
Cylinder cap
19
Nut Φ27.5*φ8.5*t3.0
20
M4 nut
21
Running board
22
Running belt
23
Multiple V-ribbed belt
24
Engine cover
25
Engine cover
26
Rear panel T1.0*23.4*43.9L
27
Lubricant reservoir∮ 45*28.5
28
Rubber round cover∮ 42.5*20.5
29
Cylinder φ38
30
Red wire 80mm
31
Black cable 80mm
32
400mm cable
33
Cover
34
Rear covers
35
Shields
36
Lubricant
37
Gasket
38
Key
39
Handle
40
Front bracket
41
Bumper
42
Counter
43
Bumpers
44
Rolls
45
Front rollers
46
Rear rollers
47
Lower communication cable
48
Adapter
49
Screw M8*12
50
Screw M8*20
CLEANING AND MAINTENANCE:
Make sure the unit is completely disconnected from the power supply before carrying out any maintenance work or cleaning the components under the
motor cover.
The components under the engine cover should be cleaned at least once a year.
It is not necessary to lubricate the tread belt or treadmill plate when the equipment is first unpacked. The lifespan of the equipment largely depends on the
condition of the tread belt and base surface - it is recommended that these are lubricated regularly to ensure that the treadmill functions correctly and
extends its life. Periodic inspection of the entire unit is also recommended. If any abnormalities or damage is detected, contact your equipment distributor
immediately.
Frequency of inspection and lubrication of the running belt depending on the intensity of use:
• Infrequent use (less than 3 hours per week): 1 time per year
• Average use (3-5 hours per week): every 6 months
• Frequent use (more than 5 hours per week): every 3 months
• It is recommended to use the original lube available from the distributor.
1. To extend the life of the machine, it is recommended that the treadmill is unplugged for 10 minutes after each workout of at least 2 hours.
2. Too little tension on the treadmill belt can cause it to slip during exercise and accelerate wear on the rollers and motor. It is recommended to
keep the belt tension such that the clearance when the belt is lifted up is between 50 and 75 mm.
Description
Quantity
Lp.
1
51
Screw M3*8
2
52
Screw M4*15
1
53
Shim∮ 4.1*∮ 4.4*t1.0
1
54
Screw M4*15
2
55
Screw M4*12
2
56
Screw M4*8
1
57
Screw M4*15
5
58
Screw M4*10
2
59
Screw M5*8
2
60
Screw M5*10
2
61
Screw M6*12
2
62
Screw M8*20
2
63
Screw M8*28
2
64
Screw M6*12
2
65
Screw M8*45
2
66
Screw M8*55
4
67
Screw M6*25
2
68
Screw M8*32
4
69
Screw M8*12
2
70
Screw M6*30
1
71
Screw M5*10
1
72
Nut M8
1
73
Safety ring∮ 10
1
74
Washer 9*∮∮ 16*t1.6
1
75
Washer 9*∮∮ 23*t1.6
2
76
Spring washer∮ 8.1*∮ 12.3*t2.1
2
77
Nut M6
2
78
Start/Stop button
2
79
Speed +/- buttons
1
80
Controller
1
81
Power supply
1
82
Power socket
2
83
Fuse
2
84
Switch
2
85
Adapter cable
1
86
Control board
4
87
Signal cable
1
88
DC motor
2
89
Shield∮ 45*T1.0*427L
2
90
Magnetic ring
4
91
Speed wire 800mm/450mm
1
92
Sticker start
2
93
Start/Stop top duct 1300mm
4
94
1300mm top speed duct
1
95
Earthing cable 250mm
1
96
150mm cable
1
97
Filter 6A
1
98
6A fuse
2
99
Grounding wire 150mm
2
100
6
Description
EN
Quantity
30
4
1
4
16
9
2
2
8
8
4
2
2
2
1
2
2
2
2
1
14
2
4
3
4
4
2
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
