WARNING
The noise emission values and vibration emis-
sion value can vary from the specified values
during the actual use of the power tool, de-
pending on the type and the manner in which
the electric tool is used, and in particular the
type of workpiece being processed.
Try to keep the stress as low as possible. For example:
Limit working time. In doing so, all parts of the operating
cycle must be taken into account (such as times in
which the power tool is switched off or times in which it
is switched on, but is not running under a load).
7 Unpacking
WARNING
The product and the packaging material are not
children's toys!
Do not let children play with plastic bags, films or
small parts! There is a danger of choking or suffo-
cating!
• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. Immediately report any damage to the trans-
port company that delivered the Product. Later claims
will not be recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the first time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
8 Assembly
ATTENTION
Always make sure the product is fully assembled
before commissioning!
ATTENTION
Ensure that the cable is not squeezed during assembly.
8.1 Fitting the feed brushes (5/6)
(Fig. 2, 3)
1. Turn the product over so that you are looking at the
underside of the product.
2. Position the left feed brush (5) and right feed brush (6)
on the feed brush holders (7).
Ensure that the mounting holes and the "L" or "R" la-
belling of the feed brush holder (7) and the respective
feed brush (5/6) match.
3. Secure the left feed brush (5) and the right feed brush
(6) with three screws (17) each. Use a Phillips screw-
driver*.
* = may not be included in the scope of delivery!
8.2 Installation of the lower push
bar (3) (Fig. 4)
1. Place the lower push bar (3) on the attachment pro-
vided for this purpose.
2. Secure the lower push bar (3) with the screws (11),
the washers (13) and the quick clamp levers (15). En-
sure that the screws (11) are fitted from the inside to
the outside.
3. Screw the quick clamp levers (15) onto the screws
(11) until the quick clamp levers (15) can still be ten-
sioned.
4. Now tighten the lower push bar (3) by moving the
quick clamp lever (15).
5. The desired working height can be set using the lower
push bar (3).
8.3 Installation of the upper push bar
(2) (Fig. 5)
1. Screw the upper push bar (2) to the lower push bars
(3) using a screw (12), a plastic washer (14) and a
quick clamp lever (15) on both sides.
You can use the upper or lower hole on the upper
push bar (2).
Ensure that the screws (12) are fitted from the inside
to the outside.
2. Screw the quick clamp levers (15) onto the screws
(12) until the quick clamp levers (15) can still be ten-
sioned.
3. Now tighten the upper push bar (2) by moving the
quick clamp lever (15).
8.4 Fitting the cable holder (16) (Fig. 6)
1. Attach the two cable holders (16) into the upper push
bar (2) and lower push bar (3) and secure the cable.
8.5 Inserting the dirt collection
container (10) (Fig. 7)
1. Place the dirt collection container (10) in the designat-
ed position.
2. Ensure that the dirt collection container (10) has been
inserted properly, since a slanted or imperfectly fitted
dirt collection container (10) will adversely affect the
sweeping result.
8.6 Assembling/removing the rubber
lip (18) (Fig. 8)
Note:
The sweeping result is generally better with the rubber lip
fitted.
For very uneven sweeping surfaces, the rubber lip can be
removed to prevent tilting.
1. Remove the two screws (19) on the left and right of
the rubber lip (18). Use a Phillips screwdriver*.
2. The rubber lip (18) can now be removed.
* = may not be included in the scope of delivery!
