Note:
The operating manual is part of this product.
It includes important instructions for the safe, proper and
economic operation of the product, for avoiding danger,
for minimising repair costs and downtimes and for in-
creasing the reliability and extending the service life of the
product. In addition to the safety instructions in this oper-
ating manual, you must also observe the regulations ap-
plicable to the operation of the product in your country.
Familiarise yourself with all operating and safety instruc-
tions before using the product. Only operate the product
as described and for the specified areas of application.
Keep the operating manual in a good place and hand
over all documents when passing the product on to third
parties.
2 Product description (Fig. 1-11)
1. Gearshift lever
1a. Operating panel
2. Upper push bar
3. Lower push bar
4. Wheels
5. Feed brush (left)
6. Feed brush (right)
7. Feed brush receptacle
8. Cover (battery)
9. Battery mount
10. Dirt collection container
11. Screw (M6x35mm)
12. Screw (M6x55mm)
13. Washer (M6)
14. Plastic disc
15. Quick clamp lever
16. Cable holder
17. Screw (M4x8mm)
18. Rubber lip
19. Screw (M4x16mm)
20. Release button (battery)
21. Battery*
* = not included in the scope of delivery!
3 Scope of delivery (Fig. 1)
Item QuantityDesignation
2. 1 x Upper push bar
3. 1 x Lower push bar
5. 1 x Feed brush (left)
6. 1 x Feed brush (right)
10. 1 x Dirt collection container
11. 2 x Screw (M6x35mm)
12. 2 x Screw (M6x55mm)
13. 2 x Washers (M6)
14. 2 x Plastic discs
16. 2 x Cable holder
15. 4 x Quick clamp lever
17. 6 x Screw (M4x8mm)
1 x Sweeper
1 x Operating manual
16 | GB
4 Proper use
The sweeper is designed for use by adults only.
The product can be used to remove sawdust, nails,
screws, leaves, garden waste and grass cuttings from
hard surfaces - such as workshops, garages and paths.
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
The product may only be operated with original parts and
original accessories from the manufacturer.
The safety, operating and maintenance specifications of
the manufacturer, as well as the dimensions specified in
the technical data, must be observed.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
Explanation of the signal words in
the operating manual
DANGER
Signal word to indicate an imminently haz-
ardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in death or serious injury.
CAUTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in minor or moderate injury.
ATTENTION
Signal word to indicate a potentially hazard-
ous situation which, if not avoided, could re-
sult in product or property damage.
