Gate Control PRO - DIN rail – Quick Guide
Attention! Do NOT connect the connector of the antenna or the terminals
of the device directly or indirectly to the protective ground, because this
may damage the device!
Attention! Do NOT use the GND terminal as a negative input for powering
the device, because this can lead to damaging the components!
-> Chapter 3.5 of the Installation and Application Manual.
DEVICE WIRING:
The product has four contact inputs and two relay outputs, which can be
configured in the programming software for the task at hand.
Inputs:
The NO or NC dry contacts should be connected between the selected input
(IN1-IN4) and the GND terminal. The input type (NO or NC) can be configured
in the programming software.
Inputs IN1 and IN2 can be used as Doorbell, Technical error, or Gate opener
inputs, while inputs IN3 and IN4 are used to connect position limit switches,
depending on the control mode chosen. The wiring should be done accordingly
for these functions to work.
Outputs and control modes:
The outputs provide normally open dry contacts between the NO and COM
terminals as the default state, and closed contacts when controlled, except for
control mode No. 3, where output OUT2 is in an activated state by default.
The relay output terminals support a maximum load of 1A @ 24V DC.
