Push the locking arm on the upper part of cylinder bracket and pull the harness
2.
towards you at the same time.
QUICK COUPLING OPTION
Connection
Connect the cylinder valve adapter with the cylinder connection manifold. Press
together until the manifold "clicks" into the cylinder valve [Fig. 10].
Check that the connection is properly locked by checking that the surfaces are in line
with each other [Fig. 10].
Disconnection
Disconnect by pressing the ring of the quick coupling away from the cylinder valve and
removing the manifold [Fig. 11].
NOTE! EXISTING EQUIPMENT CAN BE UPGRADED TO CYLINDER QUICK COUPLING.
3
INSTALLING / REMOVING HUD
INSTALLING THE WIRELESS HUD
Place one side of the HUD on an angle inside the mask and press down.
1.
Make sure the right and left side of the HUD are securely seated in the rounded
2.
areas of the mask rubber, and below the two protruding lugs on the visor.
REMOVING THE WIRELESS HUD
Lift one end of the HUD and remove it from the mask.
1.
4
ADJUSTING SIZE
NOTE! WHEN STANDING STRAIGHT WITH THE BREATHING APPARATUS DONNED THE MAJORITY OF THE WEIGHT SHALL BE
CARRIED ON THE HIPS AND NOT THE SHOULDERS.
To adjust the height of the hip belt, push the red buttons under the hip belt together
and slide the complete hip belt up or down to the correct size. [Fig. 12]
The harness can be adjusted into four different sizes. Size indications are available on
both the front and backside of the harness.
5
DONNING
NOTE! THIS SECTION DESCRIBES HOW TO DON THE APPARATUS PERFORMING A "SHORT TEST" DURING THE START-UP.
FURTHER INFORMATION REGARDING THE START-UP TEST AND INSTRUCTIONS FOR PERFORMING THE "FULL TEST" ARE
GIVEN IN SECTION 6.
Connect the breathing hose to the breathing valve. [Fig. 13]
1.
Connect the face mask and breathing valve according to the instructions given in
2.
the user manual for the face mask.
10
