When reconnecting the charging clamps to a battery, reverse polarity of the
battery can therefore not be detected!
Therefore, the charging process must be interrupted by pressing the "STOP"
button before reconnecting to a battery!
Rated voltage
Power consumption from the mains
Charging voltage
Charging voltage Float charge
Charging voltage Service mode
Charging voltage reactivation
Max. Charging current
Minimum battery voltage
Ambient temperature
Cooling
Charging characteristic
Battery types
Battery capacity
Weight (without charging cable)
To start the charging, service mode, the connected battery must have a
minimum voltage of 3 volts or more. Otherwise the unit will not start charging.
The quality of the charging voltage and charging current is very important. High
ripple will cause the battery to heat up and wear out the positive electrode. This
battery charger is characterised by a very clean voltage and a smooth current with
low ripple!
TELLERKL
- Battery charger.
- Mains cable with Schuko plug and cold appliance socket, 2 m length.
- These operating instructions
- mounted charging cable with fully insulated metal pole terminals 3 m long.
TECHNICAL DATA
90 V - 264 V 47-63 Hz
8.2 A (at maximum charging current)
14-15 V (± 0.3%) adjustable
min. 13.3 V (± 0.3%)
13.9 V ( 0.3%) adjustable
max.15.5 V ( 0.3%)
60 A (12 V) ± 3%
3 V
-20°C - 50°C
Temperature-controlled fan
IUoU
Lead-acid, lead-GEL, AGM,
LiFePO4 with BMS
25-600 Ah
2,6 kg
SCOPE OF DELIVERY
