5. Technical data
Item number
Dimensions
Overall length
Overall width
Overall height
Swivel frame support
Saw blade ø
Saw blade nut tightening
torque
Engine idle speed
Saw blade cutting speed
Weight
Drive
Engine
Rated input P1
Power output P2
Operating mode
Nominal current
Cardan shaft speed
Operating data
Log cutting height
Reversible cut
Firewood
Noise data
Measurement of the noise levels was carried out in accordance with EN ISO 3744:2010.
Sound power level in dB
Idle L / Machining L
WA WA
Sound pressure level at workstation in dB
Idle L / Machining L
LqAeq qAeq
Uncertainty K
wa/pA
The stipulated values are emission values and so do
not necessarily represent safe work station values.
Although there is a correlation between emission
levels and exposure levels, it is not possible to reli-
ably determine whether additional precautionary
measures will be required or not based on this. Fac-
tors that influence the exposure level present at any
given time in the work area include the nature of the
working area, other noise sources, e.g. the number
of machines and neighbouring work processes. The
permissible working values may vary from country to
country. However, the information should enable the
operator to evaluate the hazards and risks.
26 | GB
kwd 7.0
1905115906
mm
mm
mm
mm
mm
Nm
rpm 1380
m/sec 51
kg 128
V/Hz 380 - 420 / 50 380 - 420 / 50 380 - 420 / 50 Cardan shaft 380 - 420 / 50
kW 5.2
kW 4.0
S6 / 40%
A 16
rpm -
max. mm 240
min. mm
max. mm
max. mm
Subject to technical changes!
102.9 / 105.9
www.scheppach.com
kw 7.0
1905115902 1905115903
1060
820
1150
735
700 x 30 x 4.5 x 3.5 Z42
90
1400
51
152 156
5.2 7.5
4.0 6.0
S6 / 40% S6 / 40%
16 16
- -
60
260
370 x 250
kwd 7.0 kw 7.0
102.9 / 105.9
89.1 / 92.1 89.1 / 92.1
2 2
6. Scope of delivery
• Rocking log saw
• Allen key or open-end spanner
• Operating manual
General information
• Remove the packaging material, as well as the
packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the machine and accessory parts for trans-
port damage. In the event of complaints the carrier
and manufacturer must be informed immediately.
Later claims will not be recognised.
• If possible, keep the packaging until the expiry of
the warranty period.
kwz 7.0 kw-ze 7.0
1905115904 1905115905
1410 1500
900 900
- 1380
51 51
171 217
Cardan shaft
- 5.2
- 4.0
- S6 / 40%
- 16
460 460
250
kwz 7.0 kw-ze 7.0
107.1 / 102.6 107.1 / 102.6
92.8 / 88.5 92.8 / 88.5
2 2
