English – 2
Pos. Connection
Colour
1.1–
Single core or three
Red
1.2
core BCC cable
2.1 ABS
Orange
2.2 HPP (High Power Port)
Yellow
for additional functions
A) Output current for HPP: 1 A continuous current, peak current of
3.5 A for maximum 4 s possible
Operation
The Component Connector does not need to be put into op-
eration separately after assembly.
As the Component Connector does not have an On/Off
switch, it is always active when the eBike is switched on.
Similarly, connected components such as the Bosch eBike
ABS or eShift components do not need to be switched on
separately. If necessary, other electrical third-party compon-
ents must be switched on/off separately using an On/Off
switch.
Maintenance and Service
Maintenance and Cleaning
The Component Connector is maintenance-free. In the
event of damage or failure, contact an authorised specialist
dealer directly. If a component connected to the Compon-
ent Connector is not working even though it is switched on,
consult your bicycle dealer directly.
Transport
If you transport your eBike (e.g. in a motor vehicle trailer, on
a train, plane, etc.), we recommend switching off each of the
third-party components connected separately. This does not
apply for the Bosch eBike ABS or eShift components con-
nected.
After-sales service and advice on using products
If you have any questions about the eBike and its compon-
ents, contact an authorised bicycle dealer.
For contact details of authorised bike dealerships, please
visit www.bosch-ebike.com.
Further information on the eBike components
and their functions can be found in the Bosch
eBike Help Center.
Disposal and substances in products
You can find information about substances in products at the
following link:
www.bosch-ebike.com/en/material-compliance.
Do not dispose of eBikes and their components with house-
hold waste.
0 275 007 3CC | (11.02.2024)
An in-store return is possible, provided the retailer voluntar-
Voltage
ily offers a return or is legally obligated to do so. Refer to the
36 V
national regulations in this case.
12 V
A)
12 V
Check that your personal data has been deleted from the
device.
Batteries that can be removed from the power tool without
destruction must be removed before disposal itself and sor-
ted for separate battery collection.
Electrical and electronic equipment are collected separately
for pre-sorting by type and helps to ensure that raw materi-
als are treated and recovered properly, thereby protecting
people and the environment.
Subject to change without notice.
The drive unit, on-board computer incl. operat-
ing unit, eBike battery, speed sensor, ac-
cessories and packaging should be disposed of
in an environmentally correct manner.
In accordance with Directive 2012/19/EU
and Directive 2006/66/EC respectively, elec-
tronic devices that are no longer usable and de-
fective/drained batteries must be collected
separately and recycled in an environmentally
friendly manner.
Bosch eBike Systems
