3.2. Main screen
The main screen of the application contains a series of fields with information about heat pump operation.
Status
Operation program
3.3. Active components
This field shows the main components of the heat pump that are activated. A consumption bar is also shown for the compressor and
modulating circulator pumps.
Fan activated
Brine pump activated
Compressor in start-up phase
Compressor activated
Number of units with the compressor activated in block installations
Compressor in shut-down phase
Production pump activated
Heating units activated
Cooling units activated
Auxiliary heating/cooling unit activated
HTR system activated
//
7
Active components
Figure 3.2. Description of the main screen.
Date and time
Mon 4:5
5
39
User manual
Energy meter
Operation mode
