Characteristics; Specification - Quick Tools Quts8 Bedienungsanleitung

2.2.

Characteristics

• Direct selection buttons for 3 individual soldering parameters
• ESD protection and ESD test function
• Extremely short heating time from room temperature to 300°C in 3s
• Cartridge system, the radiator is integrated into the soldering tip
• Suitable for leaded and lead-free soldering.
• Automatic standby function, selectable from 5s – 99min.
• Programmable shutdown function.
• Digital ACTUAL and TARGET temperature display, calibratable,
password protected.
• 2 cleaning options, dry and viscose sponge.
• Alarm function for temperature windows.
• Sensor controlled, real-time monitoring of the temperature at the
soldering tip, very accurate temperature-control behavior.
• Very easy and quick to change the soldering tip.
• Soldering iron with 1.2m flexible silicone connection cable.
2.3.

Specification

Display
Rated power
Operating Voltage
Working Temperature Range
Temperature Stability
Ambient temperature
Grounding resistance
Ground-Leak Voltage
Dimensions W-H-D
Weight
Conformance
Specifications and design subject above may be changed without notice.
Color LCD TFT
150 Watt
230 Volt / 50 Hz
100 - 450 °C / 212 - 842°F
+/- 2°C
0 - 40 °C
<2 mV
137x114,5x169,6 mm
RoHS, CE
3
USER MANUAL
<2 Ω
2,9kg
