Step 4:
A. Keep the machine upward, and then screw 2PCS Hexagon Socket Flat Head
Bolts(20) into the inside of Slide Rail Assembly(A2) and the Main Frame(A1)
as shown.
NOTE:
Hold the Cushion(A7) with one hand to prevent it from falling down.
Do not tighten the screws in SETPA completely
B. Screw other 4PCS Hexagon Socket Flat Head Bolts(20) into the Slide Rail
Assembly(A2) and the Main Frame(A1).
C. Tighten all the screws by the Allen Key(T2) lastly.
NOTE:
It is recommended that two people assemble it together.
The Hexagon Socket Flat Head Bolts(20) includes the Spring Washer and Flat Washer.
7
EN
Installation Procedure
010
.
#20 Hexagon Socket Flat Head Bolts M8*20 X 6
T2 Allen Key
