EN
2.6
Technical data
Protection level
ShadeTronic®: 2.5 (bright mode), 4 < 12 (dark mode)
Manual mode: 2.5 (bright mode), 3 – 8 (dark mode)
Laser protection according to EN 207
Eyes: 1000–1100 D LB7 IR LB8 OS CE
Face: 1000–1100 D LB4 IR LB8 OS B CE
Laser protection according to ISO 19818–1
Eyes: 1000–1100 nm OD7 C5 PS3 | ISO 19818-1 OS CE
Face: 1000–1100 nm OD5 C2 PS3 | ISO 19818-1 OS E CE
UV/IR protection
Switching time from
bright to dark
Switching time from
dark to bright
Power supply
Weight
Operating temperature -10 °C – 55 °C / 14 °F – 131 °F
Storage temperature
Classification
according to EN ISO
16321-2
Approvals
Additional labels for
the PAPR version
(notified body
CE 1024)
3
Operation
3.1
Adjusting the fit of the helmet
NOTE
Risk of the lever breaking
When adjusting the distance between the eyes and the
u
helmet, press the lever slightly forwards.
– Adjust the headband
– Release the headband
– Set the distance between the eyes and the helmet
C
} [ 116]
– Adjust the helmet tilt
3.2
Disabling/enabling grinding mode
CAUTION
Risk of blinding glare!
Do not use this mode for welding.
u
– Enable grinding mode
– Disable grinding mode
3.3
Setting the welding operating mode
– Select ShadeTronic®
– Select manual mode
8
Maximum protection in bright and
dark mode
90 μs (23 °C / 73 °F)
70 μs (55 °C / 131 °F)
0.1– 2.0 s with FadeTronic
Solar cells, lithium polymer battery
Non PAPR: 685 g / 24.2 oz
PAPR: 850 g / 30.0 oz
-20 °C – 70 °C / -4 °F – 158 °F
16321 OS W2.5/3-8 /4-12 V2 +TIG
Viewing angle dependence = V2
CE, UKCA complies with
ANSI Z87.1, AS/NZS 1337.1 &
1338.1, CSA Z94.3
EN12941 (TH3 in combination with
e3000X)
EN14594 (Class 3B in combination
with supplied air)
A
} [ 116]
B
} [ 116]
D
} [ 117]
E
} [ 117]
F
} [ 117]
G
} [ 117]
H
} [ 117]
3.4
Setting the protection level
– ShadeTronic®
I
} [ 118]
– ShadeTronic® with protection level correction
J
} [ 118]
– Manual mode
K
} [ 118]
3.5
Setting the opening time
NOTE
For fast tack welding, do not set the rotary knob in the
u
"FadeTronic" area.
Use the "tack" area with a minimum opening delay.
u
– Set the delay
L
} [ 118]
– Set tack welding mode
– Set the dimming
N
} [ 118]
3.6
Adjusting the sensitivity
– Adjusting the sensitivity
3.7
Charging the battery
CAUTION
If the anti-glare guard does not function correctly despite
charging the battery, contact your official retailer. A
defective battery may only be replaced by the
manufacturer or a service centre certified by the
manufacturer.
– Charging the battery
– Check charging status
3.8
Power-assisted PAPR filter (optional)
– Fasten PAPR air hose
– Release PAPR air hose
– Fasten PAPR air hose to the holder
– Position PAPR face seal
– Adjust PAPR air supply
4
Troubleshooting
Problem
Solution
Anti-glare
Adjusting the sensitivity
u
cassette guard
Clean sensors or front cover lens
u
does not darken
W
} [ 120]
Check charging status
u
Switch off opening delay
u
Disable grinding mode
u
Protection level
Select higher protection level (manual
u
too bright
mode)
Select protection level +1 or +2
u
(ShadeTronic®)
Replace the front cover lens
u
X
} [ 121]
Protection level
Select lower protection level (manual
u
too dark
mode)
Select protection level -1 or -2
u
(ShadeTronic®)
Anti-glare guard
Adjust the position of the opening time
u
flickers
controller (delay) to the welding
technique
Adjusting the sensitivity
u
Check charging status
u
M
} [ 118]
O
} [ 119]
P
} [ 119]
Q
} [ 119]
R
} [ 119]
S
} [ 119]
T
} [ 120]
U
} [ 120]
V
} [ 120]
O
} [ 119]
Q
} [ 119]
L
} [ 118]
F
} [ 117]
K
} [ 118]
I
} [ 118]
K
} [ 118]
I
} [ 118]
L
} [ 118]
O
} [ 119]
Q
} [ 119]
