OPERATION

After you switch on the device with the power switch, the device starts running. The display lights up and you
can choose the desired mode via the buttons MENU, ENTER, UP, DOWN.
The device has two operating modes. It can be operated in stand-alone mode via the control board and the
EUROLITE IR-13 remote control or in DMX-controlled mode via a standard DMX controller and QuickDMX
with suitable wireless transmitter.

Stand-alone mode

In the stand-alone mode, you can do without a controller. Disconnect the device from the controller and call
the desired setting. Please refer to the instructions under Control Board.

Master/Slave operation

The master/slave operation enables that several devices can be synchronized and controlled by one master
device.
Set the master device and each slave device to the same transmission channel. For this purpose, press the
button ID on the device, to change the transmission channel and pair the devices.
The selected transmission channel is indicated by the status indicator.
Channel Color
1 Red
2 Green
3 Blue
4 Yellow (red/green)
5 Cyan (green/blue)
6 Magenta (red/blue)
Choose the device which is to control the effects. This device then works as master device and controls all
other slave devices.
Set the master device to the desired mode (all except Addr and SLAU). Set the slave mode (SL.AU) on
every slave device. Please refer to the instructions under Control Board.

Rechargeable Battery Operation

Prior to operating the device off mains for the first time, the rechargeable battery must be fully charged.
1
Switch on the device with the power switch. The operating time of the battery depends on the operating
mode and the ambient temperature (max. 18 hours). After the operation, switch the device off.
2
For charging the battery, connect the device to a power outlet via the enclosed power unit. Charging
time is 4 hours. The device may be operated during the charging procedure.
3
The device features a protective circuit for charging which prevents overload of the rechargeable
battery. However, disconnect the device from the mains after charging. Otherwise there will be a low
current consumption even if the device is switched off.
4
The device will heat up during charging; this is normal.
5
To prevent damage to the battery by deep discharge, recharge a battery completely discharged as soon
as possible. Do not store the unit with the battery completely discharged and regularly recharge the
battery in case of long storage.
Maximum battery run time
18 hours
Battery status
The battery charging status is indicated on the display. The battery charging status is indicated by four
levels. If all four levels are lit, the battery is fully loaded. If only one level is lit, the red one, the battery is
going flat soon. In this state, the device can be operated for a few minutes. Then an emergency switch-off
deactivates the device to protect it from total discharge.
Recharge time
4 hours
26/36 00108467, Version 1.0
