After switching on, the device will automatically detect whether DMX 512 data is received or not. If the data
is received, the display will show "d.001" with the actually set address. If there is no data received at the
DMX-input, the display will show "d001" with the actually set address.
This situation can occur if:
- the wireless receiver is not logged in to the wireless transmitter or no wireless DMX signal is received.
- the controller is switched off or defective.

DMX Protocol

3 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
4 channel mode
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Decimal Hexad. Percentage S/F
0 255 00 FF 0% 100%
Control-channel 1 - Color presets
F Color presets
Control-channel 2 - White
F White (0=off, 255=100% white)
Control-channel 3 - Dimmer
F Gradual adjustment of the dimmer intensity from 0 to 100 %
Control-channel 1 - Red
F Red (0=off, 255=100% red)
Control-channel 2 - Green
F Green (0=off, 255=100% green)
Control-channel 3 - Blue
F Blue (0=off, 255=100% blue)
Control-channel 4 - White
F White (0=off, 255=100% white)
31/36
Feature
Feature
Feature
Feature
Feature
Feature
Feature
00108467, Version 1.0
