DESCRIPTION OF THE DEVICE
Features
Outdoor battery-powered LED light with QuickDMX transceiver for mobile applications
- cordless, flexible and versatile
• Equipped with a 15 W QCL LED in red, green, blue and white
• Compact and bright
• Chrome housing
• For outdoor use (IP 65)
• With integrated QuickDMX transmitter/receiver for the wireless transmission of DMX512 signals
• Flicker-free projection
• Operation via built-in rechargeable lithium-ion battery with up to 18 hours operating time
• Integrated automatic charging of the battery with indicator
• DMX-controlled operation or stand-alone operation with Master/Slave function
• Controllable via EUROLITE IR-13 remote control; included in the delivery
• 3, 4, 6, 8 or 10 DMX channels selectable
• Functions: static colors, stepless RGBW color changing, internal programs, dimmer, strobe effect with
variable speed, sound-control
• Dimmer speed (step response) adjustable
• Addressing and setting via Control Board with touch buttons and LCD
• Hanging as well as standing installation possible
• Charger included in delivery
• Switch-mode power supply for operation between 100 and 240 volts
• DMX512 control via any standard DMX controller
Overview
(1) Housing
(2) Fixation screw
(3) Lens/LED
(4) Mounting bracket
(5) Function QuickDMX On/Off
(6) Menu button
(7) Enter button
(8) Display
(9) QuickDMX status indicator
(10) Infrared sensor for the remote
control
(11) Charge indicator
(12) Down button
(13) Up button
(14) Button ID, to change the
transmission channel and pair the
devices
(15) Housing screw
23/36
00108467, Version 1.0
