Eurolite Ir-13 Remote Control - EuroLite AKKU IP Flat Light 1 Bedienungsanleitung

UErn UEX.X
POU- PO-1/PO-2
LOC on/off

EUROLITE IR-13 remote control

1
2
3
groove to the right and at the same time remove the battery support. For operation, one 3 V button cell
type CR2032 is required. When inserting, pay attention that the positive pole of the button cell shows
upwards in the support.
Danger of explosion when battery is replaced improperly. Only replace by the same type.
Please dispose of old and used batteries properly. Batteries are hazardous waste and should
Control via IR remote
The Controller has several buttons with following functions:
Brightness up
Red
100% R + 24% G
100% R + 47% G
100% R + 71% G
100% R + 100% G
The device features a memory function. The last program selected will begin anew when the device is
restarted.
node1: Response characteristics of halogen lamps, fast
node2: Response characteristics of halogen lamps, less fast
node3: Response characteristics of halogen lamps, middle
node4: Response characteristics of halogen lamps, slow
Software version
Power-save mode
PO-1 - power save mode, 50 % power
PO-2 - full power
Lock and unlock the keys of the control board/touchscreen
In order to deactivate or temporarily deactivate the keylock function, press
the keys ENTER and DOWN at the same time.
When actuating a button, always hold the remote control in the direction of the
sensor. There must be visual connection between the remote control and the
sensor.
The remote control is supplied with a battery inserted. An insulating foil between the
battery and the battery contacts prevents the battery from being discharged during
storage. Prior to the first operation remove the foil from the battery support on the
rear side of the remote control. Otherwise operation of the remote control is not
possible.
If the range of the remote control decreases (10 meters as
a maximum), replace the battery. For this purpose, on the
rear side of the remote control press the small bar with the
not be disposed of with regular domestic waste!
Brightness down
Green
90% G + 23% B
82% G + 46% B
72% G + 69% B
100% G + 100% B
CAUTION!
OFF
Blue
22% R + 87% B
48% R + 75% B
67% R + 62% B
100% R + 100% B
28/36
ON
White
50% / 100% power
Strobe effect
Color Fading
Color Switching
00108467, Version 1.0
