Operation
Parameters
Description
SP
Set the statistic pressure for the channel wall
unit.
•
SP1: low
•
SP2: middle 1
•
SP3: middle 2
•
SP4: high
AF
Function test for three to six minutes.
tF
Offset temperature for the Follow me
function.
•
−5...0...5 °C
tyPE
Restrict the control to specific operating
modes:
•
CH: do not restrict available operating
modes.
•
CC: no heating and automatic mode
•
HH: only heating and Fan Mode
•
NA: no automatic mode
tHI
Maximum value of adjustable temperature
•
25...30 °C
tLo
Minimum value of adjustable temperature
•
17...24 °C
rEC
Switch the control on/off via the remote
control.
•
ON: on
•
OF: off
Addr
Set the addresses of the wired room
controller. If there are two wired room
controllers in the system, each wired room
controller must have a different address.
•
--: only one wired room controller in the
system
•
A: primary wired room controller with the
address 0.
•
B: secondary wired room controller with
the address 1.
Init
ON: restore factory settings.
Table 28
58
5
Operation
5.1
Overview wired room controllers
Keys of the wired room controller
Key to figure 3:
[1] Receiver for infrared remote control
[2] Display of the wired room controller
[3] Keys of the wired room controller
Key
Function
Switch on/off.
K
M
Set operating mode.
DAYOF
Day off/deletion.
F
Adjust up/down setting.
. /
Confirm choice.
TIMER
Set timer.
Fan step
Navigate back.
d
Set swing function.
FUNC.
Set function.
COPY
Copy/adopt data.
Table 29 Keys wired room controllers
Display of the wired room controller
Key to figure 4:
[1]
Display of main operating modes
[2]
Display of temperature and status
[3]
Display time
[4]
Timer display
Pos
Symbo
Explanation
.
l
1
Display of main operating modes
Operating mode: automatic mode
Operating mode: cooling mode
Operating mode: dehumidification mode
Operating mode: heating mode
Operating mode: Fan Mode
Operating mode: On/Off
K
Climate Room Control – 6721841498 (2023/04)
