You can stop the measurement at any time by pressing the
ON/OFF button or open the cuff (e.g. if you feel uneasy or an
unpleasant pressure sensation).
4. Appearance of the irregular heartbeat (IHB) symbol
This symbol AM indicates that an irregular heartbeat was detected.
In this case, the measured blood pressure may deviate from your
actual blood pressure values. It is recommended to repeat the
measurement.
Information for the doctor in case of repeated appearance of
the IHB symbol:
This device is an oscillometric blood pressure monitor that also
measures the pulse during blood pressure measurement and indi-
cates when the heart rate is irregular.
5. Traffic light indicator in the display
The bars on the left-hand edge of the display AK show you the range
within which the indicated blood pressure value lies. Depending on
the height of the bar, the readout value is either within the optimum
(green), elevated (yellow), too high (orange) or dangerously high
(red) range. The classification corresponds to the 4 ranges in the
6
table as defined by the international guidelines (ESH, ESC, JSH), as
described in «Section 1.».
6. Data memory
At the end of each measurement, this device automatically stores
the result, including date and time.
Viewing the stored values
Press the M-button 5 briefly, when the device is switched off. The
display first shows «M» AL and then a value, e.g. «M 17». This
means that there are 17 values in the memory. The device then
switches to the last stored result.
Pressing the M-button again displays the previous value. Pressing
the M-button repeatedly enables you to move from one stored value
to another.
Memory full
Pay attention that the maximum memory capacity of 30
memories per user is not exceeded. When the 30 memory is
full, the oldest value is automatically overwritten with the
31th value. Values should be evaluated by a doctor before
the memory capacity is reached – otherwise data will be lost.
