9.3.8 Bitmap Table „Extended"
9.3.9 Table „Operating States"
8012706/ZVF0/V2-1/2018-02 | SICK
Irrtümer und Änderungen vorbehalten
Additional functions, such as alarm functions are listed in Bitmap table.
Bit No. Name
0 Alarm purge air
1 Alarm optic housing temperature
2 Alarm lamp current
3 Alarm lamp integration
4 Alarm pressure (pressure < 800 hPa or pressure > 1300 hPa)
5-31 Reserved
Tabelle 34: Bitmap table for extended Functions
Value Operating state
0 not defined
1 Initialisation
2 Measuring
3 Maintenance
4 RCycle
5 Check cycle
6 ZeroAdjust
7 Alignment
8 Boxmeasuring
9 Restart
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Reserved
16 Reserved
17 Reserved
18 Reserved
19 Reserved
20 Reserved
Tabelle 35: Table „Operating states"
SPEZIFIKATIONEN
Comment
Bit=1: active
Bit=1: active;
Bit=1: active;
Bit=1: active;
Bit=1: active
