MET ONE 6000: 6003, 6005, 6013, 6015 (English)
Operation
12
Use the equation that follows to calculate the expected voltage. Make sure that the measured
and calculated voltages agree.
Voltage = < (0.002 × RL)
Where: RL = value of the load resistor in ohms
Example: for a 100-ohm resistor, the voltage should be less than 0.20 V.
13
On the Basic Setup tab, change the settings back to the previous values.
14
Click
Save Settings
Table 7 Output voltage with 100, 250 and 500-ohm resistors
Sample count
0
100
200
300
400
500
600
700
800
900
1000
RS485 serial output with Modbus RTU protocol
Instruments with the RS485 Modbus communication option use industry-standard Modbus RTU
protocol. In this communication mode, a series of registers hold data about measurement results
and operation parameters.
When a ModbusTCP connection is made, the user can use all the configuration options in the
Modbus register map. Refer to the company website for the Modbus register map. Write drivers to
communicate with the instrument through these registers with the Modbus RTU protocol.
The RS485 serial network circuit supplies communications for a maximum of 32 instruments and a
control computer. Only one instrument can transmit data at a time. Each instrument must have a
unique instrument address.
26 / 32
.
100 Ω 250 Ω
0.40 V 1.00 V
0.56 V 1.40 V
0.72 V 1.80 V
0.88 V 2.20 V
1.04 V 2.60 V
1.20 V 3.00 V
1.36 V 3.40 V
1.52 V 3.80 V
1.68 V 4.20 V
1.84 V 4.60 V
2.00 V 5.00 V
500 Ω
2.00 V
2.80 V
3.60 V
4.40 V
5.20 V
6.00 V
6.80 V
7.60 V
8.40 V
9.20 V
10.00 V
DOC026.97.80340, Edition 4
