MET ONE 6000: 6003, 6005, 6013, 6015 (English)
Installation
Electrical installation
Wiring safety information
WARNING
disconnect.
IMPORTANT
Obey all safety statements while connections are made to the instrument.
Connect to power
Connect an external power source (24 VDC) to the 5-pin or 10-pin connector. Refer to
Table 5
or
Figure 8
external power source does not exceed 28 VDC.
The maximum number of instruments that can connect to one external power source can change
with the communication option. Contact technical support for more information.
Refer to the illustrated steps in
Figure 10
for 10-pin connector wiring.
Figure 7 5-pin connector
Table 5 5-pin connector wiring
Pin
1
2
3
Common (shield ground)
Figure 8 10-pin connector
14 / 32
Electrocution hazard. Make sure that there is easy access to the local power
Always disconnect power to the instrument before electrical connections are made.
and
Table 6
for wiring information. Make sure that the output voltage of the
Figure 9
Description
—
—
for 5-pin connector wiring. Refer to the illustrated steps in
Pin
Description
4
Unit main power (9–28 VDC, 1 A maximum)
5
Common
Figure 7
and
DOC026.97.80340, Edition 4
