MET ONE 6000: 6003, 6005, 6013, 6015 (English)
Table of contents
Table of contents
Specifications,
General information,
Installation,
Specifications
Specifications are subject to change without notice.
Specification
Dimensions (W x D x H)
Enclosure
Light source
Weight
Pollution degree
Installation category
Protection class
Power requirements
Power consumption
(maximum)
Operating temperature
Storage temperature
Humidity
Altitude
Port sizes
Output signal options
Data storage
Sample flow rate
Inlet pressure
Vacuum requirement
2 / 32
2 Startup, 19
3 Operation, 20
9 Maintenance,
Details
13.56 x 8.93 x 12.06 cm (5.34 x 3.52 x 4.75 in.)
304 stainless steel
Long Life Laser™ diode, Class 3B laser
0.82 kg (1.8 lb)
2
I
III
9–28 VDC (source: Class 2 limited energy, < 150 VA)
Serial and pulse units: 3.3 W; Ethernet unit: 4.3 W; Analog: 3.5 W; 1 A maximum
5 to 40 °C (40 to 104 °F); best performance: 10 to 32 °C (50 to 90 °F)
–40 to 70 °C (–40 to 158 °F)
Operating and storage: 5 to 95% relative humidity, non-condensing
2000 m (6562 ft) maximum
Model 6003, 6005: barb fitting for 0.32 cm (1/8-in.) ID inlet tubing, 0.64 cm (¼-
in.) ID outlet tubing
Model 6013, 6015: barb fitting for 0.64 cm (¼-in.) ID inlet tubing, 0.64 cm (¼-
in.) ID outlet tubing
Pulse, analog 4–20 mA, serial RS232 with Modbus RTU or FXB communication
protocol (no networking), serial RS485 with Modbus RTU or FXB communication
protocol, Ethernet with ModbusTCP protocol
1000 samples/records (oldest records are written over when the buffer is full)
Model 6003, 6005: 0.1 cfm (2.83 Lpm) ± 5%
Model 6013, 6015: 1.0 cfm (28.3 Lpm) ± 5%
Ambient to 2.5 mm (0.1 in) Hg vacuum
≥ 406 mm (16 in.) Hg (542 mbar) minimum vacuum measured at each
instrument with flow through all instruments.
30
DOC026.97.80340, Edition 4
