14. Specification
Type
Part no.
Frame colour
Frame coating
Height
Width
Depth
Pattern dimension (incl. connectors)
Weight (dry)
2
Idle temperature (at 000 W/m )
Operating pressure min.
Permissible operating pressure
Test pressure, absorber (ex works)
Rated throughput
Collector pressure drop (300 l/h, water, 20 °C)
Connection
Heat transfer medium
Heat transfer medium content (incl. distribution line)
Total area
Aperture area
Angle of inclination (angle towards the horizontal)
Casing
Cover
Absorber
Pipes
Thermal insulation
Output*
Conversion factor η (efficiency)
0
Heat loss coefficient a
1
Heat loss coefficient a
2
Collector yield **
* Subject to global radiation levels, installation conditions, heat transfer medium temperature and system characteristics.
** The collector yield is based on a calculation of the annual energy yield in a reference system for DHW heating, with reference to EN 12975 with
a fixed coverage of 40% and a daily consumption of 200 litres in the city of Würzburg.
!
!
32 | SOL 27 BASIC
SOL 27 basic
228927
Silver
Anodised
mm 2168
mm 1168
mm 93
mm 1207 x 2168
kg 42
°C < 220
MPa (bar) 0.35 (3.5)
MPa (bar) 0.6 (6)
MPa (bar) 1 (10)
l/h 50 – 300
Pa (mbar) 3500 (35)
mm (") l.h. G 19.05 (3/4) A, r.h. union nut G 19.05 (3/4)
H-30 L/LS, ready mixed
l 1.5
m² 2.53
m² 2.44
° 20 to 85
Aluminium (salt water resistant)
Single glazed safety glass, 3.2 mm
Aluminium full area absorber, highly selectively coated
Copper, manifold pipe Ø 18 x 1.0, harp pipe Ø 8 x 0.4
Mineral wool, black backing paper, low level of gas release,
thermal conductivity class WLG 040
W/collector 0 to 1900
0.79
W/(m²K) 3.42
W/(m²K²) 0.0142
2
kWh/(m a) > 525
