INSTALLATION
SAFETY
7.
Safety
Only qualified contractors should carry out installation,
commissioning, maintenance and repair.
7.1
Instructions, standards and regulations
Observe all applicable national and regional regulations
and instructions.
7.2
Safety information
A solar collector generates heat when exposed to
!
sunlight or other types of light. This leads to collector
connectors getting very hot, even when they are
not filled. There is a risk of burns and the collector
suffering damage. Cover the collectors with opaque
material until they are fully installed. It is advisable
to leave collectors in their packaging until they
are installed.
Be careful not to drop the collector. Be careful not to
drop any objects on the collector. Do not step onto
!
the collector.
Do not leave the collector unsecured. It the collector
!
falls down, the glass may break.
8.
Equipment description
The collector is fitted with a full area aluminium absorber with
highly selective coating. The flat packing connections are routed
out of the side. The collector connection on the left side has a
male thread, and the collector connection on the right side has
a union nut.
A safety glass cover protects the collector. Operating the collector
with the prepared heat transfer medium (see "Specification")
provides the essential frost protection. The collector casing is
made from seawater-resistant aluminium.
8.1
Standard delivery
— Flat-plate collector SOL 27 basic
8.2
Accessories
Description
Flat-plate collector SOL 27 basic
Tiled roof, on end
Mounting frame R1 basic
Mounting frame R2 basic
Frame connection set RV basic
BP fixing kit
Flat roof or wall mounting, on end
Mounting frame R1 basic
Mounting frame R2 basic
Frame connection set RV basic
BF S basic fixing kit
Accessories
KTH basic collector sensor well
22
| SOL 27 BASIC
Part no.
228927
1
2
3
229320
1
-
1
229321
-
1
1
229618
-
-
1
185544
2
2
3
229320
1
-
1
229321
-
1
1
229618
-
1
-
229323
2
2
3
229322
1
1
1
Number
4
5
6
8
-
1
-
-
2
2
3
4
1
2
2
2
4
5
6
8
-
1
-
-
2
2
3
4
1
2
2
2
4
5
6
8
1
1
1
1
WWW.STIEBEL-ELTRON.COM
10
12
15
16
2
-
3
-
4
6
6
8
4
3
6
4
10
12
15
16
2
-
3
-
4
6
6
8
4
3
6
4
10
12
15
16
1
1
1
1
