SICK TTK70 SSI + Sin/Cos Betriebsanleitung Seite 25

8 Technical data
8.1 Dimensional drawings
9 Annex
9.1 Scope of delivery
9.2 Conformities and certificates
8013390/1PYA/2024-10-29 | SICK
Subject to change without notice
M12x1
(0.31)
14
(0.55)
Ø 5.5
(0.22)
Figure 10: Dimensional drawing TTK70 with M12 male connector (all dimensions in mm)
•
Linear encoder
• General safety notes
• Operating instructions
You can find additional accessories in the product information at www.sick.com.
You can obtain declarations of conformity, certificates, and the current operating
instructions for the product at www.sick.com. To do so, enter the product part number
in the search field (part number: see the entry in the "P/N" or "Ident. no." field on the
type label).
61.5
(2.42)
8 40
(1.57)
70
Ø 10
(0.39)
O P E R A T I N G I N S T R U C T I O N S | TTK70 SSI + Sin/Cos
OPERATING INSTRUCTIONS
5.5
(0.22)
en
25
