4.2 Connection overview
4.2.1 M12, 12-pin
5 Servicing
6 Decommissioning
6.1 Protecting the environment
8013390/1PYA/2024-10-29 | SICK
Subject to change without notice
Figure 8: M12 connection, 12-pin
Table 1: M12 pin assignment, 12-pin
PIN
1
2
3
4
5
6
7
8
9
10
11
12
1 This input is for electronic zeroing. If the SET cable is connected to US for more than 1.2 seconds after
it had previously been unassigned or connected to GND, the position of the encoder above the magnetic
tape corresponds to the value 0.
Warning! The SET input must be connected to GND or not be connected when the encoder is switched
on. If electronic zeroing is performed using the SET input, the synchronization between the SSI and
Sin/Cos signals is lost.
The linear encoder is maintenance-free. No repair option is provided in the event of a
defect. Please contact us if you have any complaints.
The surface of the magnetic tape can be cleaned with a soft cloth if there are high
levels of contamination.
The linear encoder is designed to minimize its impact on the environment. It uses a
minimum of energy and resources.
Always act in an environmentally responsible manner at work. For this reason,
►
please note the following information on disposal.
OPERATING INSTRUCTIONS
Signal
Calibration (for internal purposes only / connect to GND)
SSI data +
SSI data -
SSI clock -
+U
S
/Sin
Sin
/Cos
Cos
SET
1
SSI clock +
GND
