Connector panel usage will vary depending upon the factory options purchased with the model
(see the figure below). The following page contains a description of each connector port.
Required
Connection
Optional
Connection
8
C
ONNECTORS
DC
Power
0.00
Remote
HHLC
Scale
Display
Scanner
I/F
Scale
Scale I/F
(Factory
Connected)
Magellan SL™ Scanner & Scanner/Scale User's Guide
EAS
Interlock
EAS Antenna
Port
