CHASSIS ASSEMBLY
ROBOCUT
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
QTY. PART No.
2 4000006
2 4000263
20 4000352
20 4000357
1 4000360
2 4001226
8 4000316
2 4000011
2 4000775
1 4000359
8 4000442
4 4000744
2 4000777
1 4000039
4 4000010
4 4000778
4 4000024
2 4000005
2 4000004
8 4000353
4 4000032
2 4000009
6 4000776
DESCRIPTION
CHASSIS ASSEMBLY
DRIVE SPROCKET
RUBBER TRACK 250/72/47
CYLINDRIC HEAD SCREW
KNURLED WASHER
RH TRACK DRIVE MOTOR
TRACK MOTOR COVER
FLANGED HEAD SCREW
COVER PLATE
TENSIONER COVER
LH TRACK DRIVE MOTOR
FLANGED HEAD SCREW
TRACK BLOCKING
SEAL KIT
UNDERCARRIAGE HOUSING
BUSH
SEAL
CIRCLIP
SPROCKET
SPROCKET FORK
FLANGED HEAD SCREW
ROLL PIN
PIN
BEARING
3
