ELECTRICAL COMPONENTS
ROBOCUT
REF. QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
13a
13b 21
13c
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
35A
36
37
38
39
40
PART No.
1 4000283
1 4000284
4 4000823
5 4000544
5 4000789
4 4000824
4 4000452
2 4000181
1 4000306
1 4000307
1 4000308
2 4000309
1 4000825
4 4000302
4000303
1 4000311
1 4000145
1 4000313
1 4000326
1 4000802
4 4000316
4 4000789
4 4000075
1 4000826
1 4000318
1 4000798
1 4000799
1 4000301
3 4000316
4 4000827
8 4000791
8 4000321
1 4000322
1 4000828
1 4000829
1 4000830
1 4000831
1 4000729
1 4000730
1 4000833
1 4000834
1 4000835
4 4000836
1 4000837
DESCRIPTION
ELECTRICAL COMPONENTS
ROTATING LIGHT (BEACON)
LIGHT CONNECTION
WASHER
WASHER
WASHER
SCREW
SCREW
BATTERY
RED EMERGENCY SWITCH
PLUG
CONNECTOR
SCREW
RELAYS FUSE BOX
RELAY WITH DIODE
MICRO RELAY
FUSE
IGNITION SWITCH
PRE AIR HEATER
INJECTION PUMP DELAY
ELECTRICAL BOX
SCREW
WASHER
NUT
WIRING LOOMS - ELECTRICAL SYSTEM
CONNECTOR PLUG
WASHER
LOCK NUT
HORN
SCREW
WASHER
LOCK NUT
WASHER
SHUNT BOX
SOUNDPROOF PROTECTION
CONTROL UNIT
INDICATOR
BOX PROTECTION
RECEIVER UNIT (870 MHZ)
RECEIVER UNIT (915 MHZ)
WIRING LOOM - CONTROL UNIT
SUPPORT RECEIVER
CLIP
DISTANCE PIECE
WIRING LOOM - CHASSIS LINE
