ACTUATOR ASSEMBLY
ROBOCUT
REF. QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
Bracket Part No. 4000057 has been discontinued; replacement of this bracket
now requires the use of Actuator Bracket Conversion Kit (Part No. 4001397)
- this kit converts the assembly to the same arrangement as current builds.
REF. QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
PART No.
1 4000057
1 4000441
2 4000442
1 4000086
3 4000381
4 4000078
1 4000806
4 4000316
1 4000058
1 4000059
1 4000074
1 4000060
2 4000443
PART No.
1 4001408
2 4000441
2 4000442
1 4000086
3 4000380
4 4000078
1 4000806
4 4000316
1 4000058
1 4001407
1 4000074
1 4000060
2 4000443
1 4001406
DESCRIPTION
ACTUATOR ASSEMBLY (Early Builds)
BRACKET (Item discontinued)
COUNTERSUNK HEAD SCREW
FLANGED HEAD SCREW
ACTUATOR
AUTOGRIP NUT
WASHER
HEX HEAD SCREW
FLANGED HEAD SCREW
THROTTLE BRACKET
ACTUATOR ARM
THROTTLE SPRING
ACTUATOR SPRING LINKAGE
AUTOGRIP NUT
DESCRIPTION
ACTUATOR ASSEMBLY (Current Builds)
BRACKET
COUNTERSUNK HEAD SCREW
FLANGED HEAD SCREW
ACTUATOR
AUTOGRIP NUT
WASHER
HEX HEAD SCREW
FLANGED HEAD SCREW
THROTTLE BRACKET
ACTUATOR ARM
THROTTLE SPRING
ACTUATOR SPRING LINKAGE
AUTOGRIP NUT
BRACKET
