RADIATOR COVERS ASSEMBLY
ROBOCUT
REF. QTY.
1 1
2 41
3 41
4 1
5 2
6 2
7 2
8 2
9 2
10 1
11 1
12 1
PART No. DESCRIPTION
RADIATOR COVERS ASSEMBLY
RADIATOR BONNET ASSEMBLY - comprising of:
4000401
4001229 LOCKNUT
9100102 WASHER
4000155 CENTRAL LOWER MESH
4000154 SIDE MESH
4000107 CYLINDRIC HEAD SCREW
4000798 WASHER
4000799 LOCKNUT
4000112 BONNET FASTENER
4001230 RADIATOR BONNET
4000374 CENTRAL UPPER MESH
RUBBER SEAL (not illustrated)
4001368
15
