PUMPS ASSEMBLY
ROBOCUT
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
(Builds S/No: ►ROBO071100027 )
QTY. PART No.
1 4000429
9 4000410
8 4000209
1 4000297
8 4000430
1 4000431
1 4000432
1 4000296
2 4000433
6 4000434
6 4000435
1 4001312
1 4001313
1 4000438
1 4001314
1 4001315
1 4001316
1 4000440
1 4000758
1 7315797
DESCRIPTION
PUMPS ASSEMBLY (Early Builds)
Machines S/N: ►ROBO071100027
FLYWHEEL PUMP ADAPTOR
KNURLED WASHER
HEX HEAD SCREW
FLYWHEEL
FLANGED HEAD SCREW
PUMP MANIFOLD
GROOVED JOINT
ROTOR PUMP
PUMP CLAMP
LOCK WASHER
HEX HEAD SCREW
TANDEM PISTON PUMP
GEAR PUMP
O RING
O RING
DRIVE COUPLING
PUMPS ASSEMBLY
SETCREW
WASHER
CONNECTOR
27
