MACHINE COVERS ASSEMBLY
ROBOCUT
REF. QTY.
1 4
2 4
3 4
4 17
5 1
6 1
7 12
8 1
9 1
10 1
11 6
12 16
13 2
14 6
15 2
16 2
17 12
18 2
19 4
20 1
21 6
22 6
23 1
24 1
25 1
26 2
27 2
28 2
29 2
30 2
31 2
32 4
PART No. DESCRIPTION
MACHINE COVERS ASSEMBLY
4000386 ANTI-VIBRATION BLOCK
9163003 LOCK NUT
4000321 WASHER (LARGE SERIES)
4000353 FLANGED HEAD SCREW
4000800 RUBBER GASKET
4000801 ELECTRICAL BOX COVER
4000388 RUBBER WASHER
4000161 VALVE COVER PLATE
4000162 TANK COVER PLATE
4000168 OIL SUMP PROTECTION
4000376 SCREW
4000321 WASHER
4000107 CYLINDRIC HEAD SCREW
4000316 FLANGED HEAD SCREW
4000153 BATTERY COVER
9163001 LOCKNUT
4000387 HEX SKT BUTTON HEAD SCREW
4000112 BONNET FASTENER
9100101 WASHER
4000098 ELECTRIC BOX MOUNTING FRAME
9100104 WASHER
9100204 SPRING WASHER
4000099 REMOTE RECEIVER MOUNTING
4000803 UPPER BONNET ASSEMBLY - comprising of:
4000804
4000163
4000384
4000381
4000075
9100103
4000385
4000251
UPPER BONNET
BUSHING
HEADLESS SCREW
AUTOGRIP NUT
AUTOGRIP NUT
WASHER
WASHER
ANTI-VIBRATION BLOCK
17
