DIESEL ENGINE
ROBOCUT
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
QTY. PART No.
1 4000701
1 4000275
1 4000054
7 4000353
8 4000381
1 4000380
1 4001231
2 4000806
8 4000385
2 4000084
2 4000389
2 4000080
2 4000807
1 4001232
2 4000416
2 4000390
2 4000068
2 4000083
2 4000391
1 4001415
1 4000046
6 4000808
4 4000607
1 4000392
1 4000393
1 4000041
11 4000394
1 4000047
1 4000043
1 4000042
1 4000395
1 9100203
1 9100103
1 4000396
8 9100104
6 9100204
4 9313074
1 4000286
2 4000397
1 4000400
1 4000052
1 4000048
1 4000051
DESCRIPTION
DIESEL ENGINE
ISUZU ENGINE (40HP)
MOTOR BELT
AIR FILTER MOUNTING
FLANGED HEAD SCREW
AUTOGRIP NUT
FLANGED HEAD SCREW
RADIATOR BRACKET
HEXAGON HEAD SCREW
WASHER (LARGE SERIES)
ANTI-VIBRATION RUBBER
SPACER
WASHER (LARGE SERIES)
HEXAGON HEAD SCREW
RADIATOR SUPPORT BRACKET
AUTOGRIP NUT
WASHER
HEADLESS SCREW
ANTI-VIBRATION MOUNTING
SPACER
RADIATOR*
RADIATOR* c/w COWL
LOCKNUT
HEAVY DUTY HOSE CLIP
RADIATOR HOSE LEFT
RADIATOR HOSE RIGHT
LEFT MESH GUARD
FLANGED HEAD SCREW
RADIATOR PROTECTION
UPPER MESH GUARD
RIGHT MESH GUARD
SCREW
WASHER
WASHER
ANTENNA BRACKET
WASHER
SPRING WASHER
SETSCREW
LIGHT BRACKET
CLIP
AIR FILTER COMPLETE c/w CLIP
AIR FILTER BRACKET
AIR FILTER HOUSING
AIR FILTER COVER
Continued ...
21
McCON NEL
(for Pneumatic Fans only)
