McConnel robocut Betriebsanleitung Seite 150

ROTORS & FLAILS
ROBOCUT
REF. QTY.
1 1
2 2
3 2
4 1
5 1
6 2
7 1
8 1
9 2
10 1
11 2
12 1
13 1
1
1
1
1
PART No. DESCRIPTION
ROTORS & FLAILS ASSEMBLY
4000190 1.3M ROTOR (Y-FLAILS TYPE)
4000241 STEEL BUSHING
4000242 Y-FLAIL (6mm)
HAMMER FLAIL (Early Type) ►06/14
4000243
4000244 1.3M ROTOR (HAMMER FLAIL TYPE)
4000245 BUSHING
4000703 1.3M ROTOR C/W Y-FLAILS
4000704 1.3M ROTOR C/W HAMMER FLAILS
4000246 SCREW
4000247 SCREW
4000248 AUTOGRIP NUT
4000249 AUTOGRIP NUT
HAMMER FLAIL (Later type) 06/14►
4001091
SINGLE STATION FLAIL KITS
4000255 Y-FLAILS KIT (6mm Flail)
HAMMER FLAIL KIT (Flail 4000243) ►06/14
4000256
HAMMER FLAIL KIT (Flail 4001091) 06/14►
4001092
22 STATION FLAIL KIT
4000268 Y-FLAILS KIT (6mm Flail)
63
