HYDRAULIC ASSEMBLY
ROBOCUT
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
QTY. PART No.
1 4001389
1 4001390
1 4000765
1 4000766
1 4000767
3 7315797
2 4000579
3 4000748
2 4000587
1 4000133
1 4000139
2 4000136
2 4000137
1 4000132
1 4000140
1 4000135
1 4000668
1 4000229
1 4000186
4000716
4001297
DESCRIPTION
HYDRAULIC ASSEMBLY
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
CONNECTOR
CONNECTOR
CONNECTOR
CONNECTOR
CONNECTION
PLUG
CONNECTION
PLUG
CONNECTION
PLUG
CONNECTION
PLUG
MOTOR
HYDRAULIC RAM
MOTOR SEAL KIT
RAM SEAL KIT
