INTAKE & DRAIN PUMPS
ROBOCUT
REF.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
QTY. PART No.
1 4000533
1 4000534
1 4000535
1 4000536
1 4000537
1 4000538
1 4000539
1 4000540
1 4000541
7 7315797
2 7315777
1 7315775
4 7315774
1 4000542
6 4000543
6 4000544
2 4000545
1 4000546
2 7315769
2 4000547
1 4000548
2 4000549
2 4000550
2 4000551
8 4000353
1 4000552
1 4000553
2 9100204
2 9100104
1 4000864
DESCRIPTION
INTAKE & DRAIN PUMPS
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
CONNECTOR
CONNECTOR
CONNECTOR
CONNECTOR
CONNECTOR
CYLINDRIC HEAD SCREW
SPRING WASHER
PUMP CONNECTION
CHECK COUPLING
CHECK COUPLING
HEX HEAD SCREW
O RING
O RING
O RING
VALVE BLOCK BRACKET
FLANGED HEAD SCREW
OIL MANIFOLD
VALVE BLOCK
SPRING WASHER
FLAT WASHER
PLUG
