McConnel robocut Betriebsanleitung Seite 142

HYDRAULIC RAMS CIRCUIT
ROBOCUT
REF.
1
2
3
4
5
6
7
8
9
10
11
12
QTY. PART No.
1 4000583
1 4000584
1 4000585
1 4000586
4 4000579
2 4000587
2 4000588
1 4000882
1 4000697
2 4000368
2 4000101
2 4001409
2 4000883
2 4001410
DESCRIPTION
HYDRAULIC RAMS CIRCUIT
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
HYDRAULIC HOSE
CONNECTOR
CONNECTOR
TEE FITTING
RESTRICTOR
RESTRICTOR
GREASE NIPPLE
HYDRAULIC RAM (S/No. ►ROBO031400417)
HYDRAULIC RAM (S/No. ROBO031400418 ►)
RAM SEAL KIT (For Hydraulic Ram 4000101)
RAM SEAL KIT (For Hydraulic Ram 4001409)
