FLAILHEAD ASSEMBLY
ROBOCUT
REF. QTY.
1 1
2 2
3 2
4 1
5 1
6 1
7 1
8 1
9 1
10 2
11 1
12 1
13 1
14 1
15 1
16 1
17 2
18 1
19 1
20 1
21 1
22 1
1
23 1
1
24 1
25 1
26 1
1
27 1
28 1
29 2
30 1
31 1
32 2
33 1
34 1
35 1
36 1
When replacing the now obsolete early type Spring 4000219 with the later type Spring 4000749
the early type Bracket 4000204 must also be replaced with later type bracket 4000338.
PART No. DESCRIPTION
FLAILHEAD ASSEMBLY
4000182 CYLINDER FIXING STIRRUP
4000184 STOP BRACKET
4000183 RUBBER STOP
4000185 RAM BRACKET
4000186 HYDRAULIC RAM
4000187 HEAD CASING (1.3m)
4000188 CLAMP STRIP
4000189 RUBBER FLAP
4000190 ROTOR (1.3m)
4000191 ROTOR BEARING SUPPORT
4000192 HEAD PIVOT BRACKET
4000193 PIVOT JOINT
4000194 ROLLER
4000195 ROLLER BRACKET - R/H
4000196 ROLLER BRACKET - L/H
4000197 LEFT SKID
4000198 WASHER
4000199 PLATE
4000200 RIGHT SKID
4000201 MOTOR MOUNTING PLATE
4000202 BELT COVER
FRONT HOOD (Builds to S/N ROBO071300390)
4000203
FRONT HOOD (Builds from S/N ROBO071300391)
4001257
SPRING BRACKET (Fits Spring 4000219 only)
4000204
SPRING BRACKET (Fits Springs 4000219 & 4000749)
4000338
4000205 SPRING TENSIONER FIXING
4000206 SPRING TENSIONER
4000255 Y-FLAILS KIT (SINGLE STATION)
4000268 Y-FLAILS KIT (22 STATION)
4000208 SCREW
4000252 SCREW
4000209 SCREW
4000210 SCREW
4000211 SCREW
4000212 SCREW
4000213 SCREW
4000214 SCREW
4000215 SCREW
4000216 SCREW
4001297 SEAL KIT FOR HYDRAULIC RAM 4000186
