ENGINE COVERS ASSEMBLY
ROBOCUT
REF. QTY.
1 1
2 1
3 8
4 12
5 12
6 2
7 4
8 1
9 5
10 1
11 4
12 4
13 1
14 2
15 1
16 2
17 4
18 2
19 8
20 2
21 2
22 1
23 1
24 4
25 4
26 4
27 4
28 1
PART No. DESCRIPTION
ENGINE COVERS ASSEMBLY
4000169 RADIATOR LEFT SUPPORT
4000170 RADIATOR RIGHT SUPPORT
4000176 HEADLESS SCREW
4000075 AUTOGRIP NUT
9100103 WASHER
4000375 SIDE PROTECTION SUPPORT
4000379 FLANGED HEAD SCREW
4000164 RIGHT SIDE BONNET
4000380 FLANGED HEAD SCREW
4000172 REAR COVER
9100104 WASHER
4000381 AUTOGRIP NUT
4000165 LEFT SIDE BONNET
4000353 FLANGED HEAD SCREW
4000167 AIR FILTER BONNET SUPPORT
9163001 LOCK NUT
9100101 WASHER
4000383 HINGE
4000378 COUNTERSUNK HEAD SCREW
4000377 CYLINDRIC HEAD SCREW
4000316 FLANGED HEAD SCREW
4000171 RADIATOR CLOSING SUPPORT
4000795 AIR FILTER BONNET KIT - comprising of:
4000609
9100104
4000376
9100204
4000166
13
ANTI-VIBRATION BLOCK
WASHER
SCREW
SPRING WASHER
AIR FILTER BONNET
