Fitting the
1
mounting bra-
cket (individual-
ly)
3
IMPORTANT! Drill a Ø5.8 mm hole for the mounting bracket and use a reamer to
enlarge the hole so it can accommodate the dowel pin (Ø6G7).
IMPORTANT! The mounting bracket must be fitted using an M8 shoulder screw.
The required bracket must then be positioned and two dowel pins (Ø6 mm) dri-
ven in to secure it.
Fitting the wire IMPORTANT! When cutting the wire guide core, ensure that:
guide core -
-
-
Danger from work that is not carried out properly.
This can result in serious damage to property.
▶
* A torque wrench and the matching socket wrench are available instead of the
tool supplied as standard. This ensures that it is possible to tighten the compon-
ents with the torque specified. See spare parts list for item number.
no burr juts out into the wire guide core on cutting
place the side cutter slightly at an angle (burr is pulled outward)
grind the burr off
CAUTION!
It is imperative that the sequence of work steps is complied with and the tor-
ques specified adhered to.
2
Reibahle /
Reamer /
Alésoir /
Alesatore /
Escariador /
Alargador
Ø6G7
Bohrer /
Drill /
Foret /
Punta del
trapano /
Broca /
Broca
Ø5,8
