It is the installer/owner's responsibility to check and
ensure compliance with the specific local regulations prior
to installation. Jacuzzi Europe S.p.A. gives no guarantee in
this respect and declines all responsibility for the compli-
ance of the installation carried out.
Technical specifications
Virtus Pro ( 1a-b-c) includes:
- the three-phase (A1) or single-phase (A2) spa-pack control
unit.
Note: a booster-kit spa-pack (optional, B) can be installed and
connected to the one supplied as standard; please see the relative
documentation.
- the hot tub, to be connected to the spa-pack and drain using
the piping.
- the balance tank (some models are equipped with built-in bal-
ance tanks - F1, 1a - others have an external balance tank
- F2 or F3, 1b or 1c).
MAXIMUM POWER ABSORPTION OF SYSTEM
- three-phase version (with heater)
Spa-pack A1
Power supply (x)
consumption
Volts Hertz Ampere
41.5
(*)
220 - 240 3~ 50/60
(k)
24
380 - 415 3N~ 50/60
(k)
- three-phase version (with exchanger)
Spa-pack A1
Power supply (x)
consumption
Volt Hertz Ampere
11.5
220 - 240 3~ (*) 50/60
(k)
380 - 415 3N~ 50/60 6.5
(k)
- single-phase version (with heater)
Spa-pack A2
Power supply (x)
consumption
Volt Hertz Ampere
220 - 240 50/60 22.5
(k)
- single-phase version (with exchanger)
Spa-pack A2
Power supply (x)
consumption
Volt Hertz Ampere
220 - 240 50/60 16
(k)
(k): at 230 V - (j): absorbed power
(x): see the "Preparing the electrical connections" chapter
(*): special standard (not valid for Europe)
Jacuzzi Europe S.p.A. © 2023
Spa-pack Bk Audio consumption
consumption (optional)
kW Ampere kW
16.5
(j)
3.5 0.7
16.5 (k) (j)
(j)
Spa-pack Bk Audio consumption
consumption (optional)
kW Ampere kW
4.5
(j)
3.5 0.7
4.5 (k) (j)
(j)
Spa-pack Bk Audio consumption
consumption (optional)
kW Ampere kW
5.15 3.5 0.7
(j) (k) (j)
Spa-pack Bk Audio consumption
consumption (optional)
kW Ampere kW
3.65 3.5 0.7
(j) (k) (j)
The electrical system that powers the hot tub must be sized for
maximum consumption (as shown in the relevant tables).
HEAT EXCHANGER
- MAX primary inlet temperature .................................................... 50 °C
- Connections ............................................................................................ 3/4"
- Primary circuit flow rate .............................................................. 38 l/min
- Primary pressure drop ............................................................0.271 m H
WEIGHT
- Virtus Pro (with integrated compensation tanks,
Net
Average volume
weight
of use
kg litres
~ 360 ~ 1500
- Virtus Pro (without integrated compensation tanks,
Net
Average volume
weight
of use
kg litres
~ 330 ~ 1500
- compensation tank (
"standard" ( 4b)
low compensation
tank ( 4c)
(optional)
kW
- spa-pack A1/A2
0.25
(j)
max weight
at full load
kg
~ 285
(optional)
kW
- spa-pack Bk ("booster kit", optional)
max weight
0.25
at full load
(j)
kg
~ 140
(optional)
kW
0.25
Components
(j)
The components and connections you need to build the sys-
tem are listed below (see
(optional)
kW
Hot tub and pipework
0.25
1 hot tub control buttons
(j)
1a hot tub lighting system
2a,b,c to the balance tank (where applicable)
3 hot tub drain
4 hydro suction line
21
MAX Max.
Resting
surface
water volume total weight
litres kg
~ 2040 ~ 2400
MAX Max. Resting
surface
water volume total weight
litres kg
~ 1610 ~ 1940
2b/c)
Max.
Resting
Load on resting surface
total weight
surface
2
kg m
~ 925 ~ 1,2
~ 900 ~ 1,8
resting ground
surface
load
2 2
m kg/m
~ 1.1 ~ 260
resting ground
surface
load
m 2 litres
~ 0.5 ~ 280
2a-b-c).
Jacuzzi Europe S.p.A. © 2023
O
2
2a)
Load on rest-
ing surface
m 2 kg/m 2
~ 5 ~ 480
2b/c)
Load on rest-
ing surface
2 kg/m 2
m
~ 5 ~ 390
2
kg/ m
~ 770
~ 500
