Always still keep a firm grip and a good level to maintain control of the tool in doubt.
The most common effects are:
• setback
• recoil,
• retreat
Kickback
The setback can occur when the moving saw chain meets at the upper quarter of the guide rail on a
solid object or is pinched.
The cutting force exerted on the chain from the saw, a rotational force in the opposite direction to
the chain travel. This leads to an upward movement of the guide rail.
Avoid kickback
The best protection is to avoid situations that lead to setbacks.
1. Keep the position of the upper guide rail always in mind.
2. Leave this place never come into contact with an object. Cut anything with it. Be especially care-
ful near wire fences and cutting small, hard knots, in which the chain can easily pinch.
3. Cut only one branch at a time.
Withdrawal
The withdrawal occurs when the chain on the underside of the bar suddenly stuck because it is
jammed or encounters a foreign object in the wood. The chain then pulls the saw forward. The with-
drawal often happens when the chain is not running at full speed when in contact with the wood.
Avoid withdrawal
Be aware of the forces and situations that can lead to jamming of the chain on the underside of the
bar.
Always start with running at full speed chain to cut.
Recoil
The recoil occurs when the chain on top of rail suddenly stuck because it is jammed or encounters a
foreign object in the wood. The chain can jerkily hold the saw against the operator. Rebounds hap-
pen often if the top rail is used for cutting.
Avoid recoil
Be aware of the forces and situations that can lead to jamming of the chain on top of rail.
Do not cut more than one branch at a time.
Do not tilt the rail to the side when you pull them out of a cutting gap, since the chain could get
caught otherwise.
10. Maintenance
WARNING: Always wear protective gloves when working on or around cutting tools. For non-use,
transport or storage always attach the transport guard to all cutting tools. Fig. 1 (14a, 15a, 17a)
Before performing any maintenance or cleaning work, always turn off the engine and pull out the
spark boot
plug.
1. Do not spray the unit with water. It damages the engine.
2. Clean the unit with a cloth, hand brush, etc.
GB | 55
