Ingeteam INGECON SUN 3Play Handbuch Seite 96

Ingeteam
Alarm
Lighting*
Orange,
FW update
constant
Grid consumption Orange, 1
Low power PV conn. Orange, 1
Power supply fault Red, 1
Idc fed to grid Red, 3
Setting change Red, 1
Insulation alarm Orange, 5
Saturation alarm Iac Orange, 5
Low Vdc Orange, 1
Shut-off due to Orange,
burn-out constant
* The number of flashes is indicated.
96
LED
Description
Inverter shutdown due to firmware
load
Grid consumption power out of the
permitted range
The generated power in the PV
array is not sufficient to connect to
the AC grid
Power supply fault to the
electronic circuit boards
DC current fed to the grid out of
the permitted range
Inverter setting change
Insulation resistance out of range
AC current saturation
Low DC voltage
Inverter shut off during the
burn-out test
Solution
Normal shutdown due to inverter firmware update.
This may be due to a low irradiance level. Otherwise,
check the PV array.
Check the correct connection of the DC cables.
Open the unit and check the correct connection of
the control board.
Check the installation in the AC part.
If the error persists, contact the Technical Service.
Normal shut down due to a change in the inverter
setting.
Search for an insulation fault in the PV array.
Check the installation in the AC part.
If the error persists, contact the Technical Service.
This may be due to a low irradiance level. Otherwise,
check the PV array.
Shut down occurred during the factory tests.
ABI2011IQM01_A - Installation and usage manual
Troubleshooting
